Aeropleat® III Pleated Panel Filter – MERV 8, 24″ × 1″ × 24″ (Standard Box)

Description

• Medium capacity pleated panel filter
• Optimum blend of cotton and synthetic fibres provides medium grade ASHRAE performance and increased dust-holding capacity
• Welded wire media grid is treated for corrosion resistance and prevents media oscillation or pull-away
• High wet-strength beverage board frame creates a rigid and durable filter pack
• Efficiency MERV 8 when evaluated per ASHRAE Standard 52.2-2007 and a MERV-A of 7 when evaluated under Appendix J of that Standard
• Applications include commercial buildings, educational facilities and specialty manufacturing
• As a pre-filter the Aeropleatl llI offers protection for the higher efficiency final filters required for today’s high technology applications; ; Note: Initial resistance to airflow (inches w.g.) Other sizes also available.
• Width: 24″
• Depth: 1″
• Height: 24″
• MERV Rating: 8
• Filter Type: Box
• Manufacturer Part Number: 119303005
• CFM Medium: 700
• CFM High: 1400
• Resistance Medium: 0.11
• Resistance High: 0.23
• Media Area sq.ft.: 0.23
• Pleats/foot: 12
